When debugging the machine, it is necessary to check the action and function of the machine first, and every button and knob needs to be tested, and the label is put on the test. After the detection is correct, the machine can be debugged for the label, and the most important point of the double-sided labeling machine is whether the card is smooth, which determines the quality of the machine debugging. Under the effect of the conveyor wheel, the label enters the sub-standard wheel, and then passes through the power wheel, in the case of the electric eye induction, the conveying wheel stops moving, thereby completing the sub-standard, wherein the tightness of the sub-standard wheel determines whether the sub-standard is one, the power wheel needs to play the role of traction label, and the position of the electric eye determines whether to continue to issue the bid, when each step is debugged, the sub-standard of one by one can be completed. After that, the label is completed by attaching the sample to the rubber tray.
During commissioning, some of the problems and solutions that arise from the double-sided labeling machine are as follows:
1. There are multiple labels or no labels on the card
1. The distance between the sub-standard wheel and the conveyor belt is not adjusted well, too tight will lead to no labeling, and too loose will lead to multiple labels.
2. The position of the electric eye of the measuring target is not set well, and the label cannot be sensed, and the conveyor wheel does not stop, resulting in continuous bidding.
3. The clutch of the machine can not brake in time, and the screws may be loose.
Second, when the label passes through the rubber disc wheel, it cannot continue to issue the standard, and the label is stuck
1. The gap between the rubber disc wheel and the label roller is too small, resulting in the label being unable to pass through.
2. The rubber squeeze shaft on the rubber disc wheel is not well combined with the rubber disc wheel, and there are too many protrusions, resulting in card labeling.
3. The labeling error of the double-sided labeling machine is too large
1. Adjust the label well by adjusting the position of the label slot of the machine.
2. Adjust the axis of the sample to change the movement of the sample.
